Techkey New Stock

• RELAY PCB SPCO 5VDC
• Relay Type: General Purpose
• Coil Voltage VDC Nom: 5V
• Contact Current Max: 5A
• Contact Voltage AC Nom: 240V
• Coil Resistance: 125ohm
• Contact Configuration: SPCO
• Coil Type: DC, Monostable
• Nom Operating Power: 200mW
• Relay Mounting: PCB
• External Height: 10mm
• External Width: 10mm
• External Depth: 20mm
• Approval Bodies: VDE
• Approval Category: UL Recognised
• Contact Configuration: SPCO
• Contact Current AC Max: 5A
• Contact Material: Silver / Nickel
• Contact Voltage AC Max: 250V
• DC Coil Power: 200mW
• External Length / Height: 10mm
• Mounting Type: PCB
• No. of Poles: 1
• Operating Temperature Max: 85°C
• Operating Temperature Min: -40°C
• Operating Time: 5ms
• PCB Hole Diameter: 1.3mm
• Release Time: 2ms
• Series: PE
• Switch Current Max: 5A
• Switching Current Max: 5A

For more information , pls contract with our sales or email us info@tk-ic.com
